Figure 362: Installing the VROC module
▶
Connect the VROC module to the VROC connector on the system board.
Concluding steps
▶
"Reassembling" on page
60
.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
16.8.2 Removing the VROC module
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
System board and components
RX2540 M6 Upgrade and Maintenance Manual 517
