Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

You may notice a slight performance impact during rebuild.
5.3.13 Looking for MAC/WWN/GUID and SAS addresses
5.3.13.1 Basic information
The customer needs to know the new address of the controller:
–
When replacing the system board with an onboard LAN controller
–
When adding or replacing a network controller
–
When adding or replacing a SAS controller
Dif
ferent controllers send different addresses:
–
LAN controller: MAC (Media Access Control) address
–
Fibre channel controller: WWN (World Wide Name) address
–
Infiniband controller: GUID (Globally Unique IDentifier) address
–
SAS controller: SAS (Serial Attached SCSI) address
5.3.13.2 Looking for the MAC address of a LAN controller
There are several possible locations where these addresses can be found.
▶
Inform the customer about the new or changed MAC address.
Checking the label
▶
If available, check the label on the controller. Beside the part number, you
may find the MAC address.
Using the BIOS
▶
Enter the BIOS.
▶
Select the Configuration menu.
Basic software procedures
RX2540 M6 Upgrade and Maintenance Manual 107

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
