Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

9.7.3 Replacing an internal RAID riser module
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 49
.
▶
"Suspending BitLocker functionality" on page 87.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
"Removing the fan cage" on page 74.
▶
"Locating the defective component" on page 50.
Removing the defective expansion card
▶
Remove the internal RAID riser module, see "Removing the internal RAID
riser module" on page 273.
▶
Remove the expansion card, see "Removing the expansion card from the
internal RAID riser module" on page 274.
Installing the new expansion card
▶
Install the expansion card, see "Installing the expansion card into the
internal RAID riser module" on page 267.
▶
Install the internal RAID riser module, see "Installing the internal RAID riser
module" on page 271.
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 277

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
