Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

▶
Connect the power cable to the RDX drive (1).
▶
Connect the end of the power cable to connector "PWR6" on the system
board.
▶
Connect the USB cable to the RDX drive (2).
▶
Connect the end of the USB cable to connector "USB4" (see close-up) on
the system board.
Concluding steps
▶
"Installing the fan cage" on page
76
.
▶
"Reassembling" on page 60.
▶
"Connecting the power cord" on page 65.
▶
"Switching on the server" on page 69.
▶
If applicable, "Installing the front cover with lock" on page 69.
▶
"Resuming BitLocker functionality" on page 105.
13.5.2 Removing the RDX drive
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Removing backup and optical disk media" on page 90
.
▶
"Suspending BitLocker functionality" on page 87.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
Accessible drives
RX2540 M6 Upgrade and Maintenance Manual 437

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
