Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

14.3 Common operation panel (COP)
14.3.1 Replacing the COP
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Software: 5 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
– Phillips PH1 / (+) No. 1 screw driver (for COP)
Note on system information backup/restore
The COP contains the Chassis ID EPROM that contains system information
like server name and model, housing type, serial number and manufacturing
data. To avoid the loss of non-default settings when replacing the system
board, a backup copy of important system configuration data is automatically
stored from the system board NVRAM to the Chassis ID EPROM.
CAUTION
For that reason the COP and the system board must not be replaced
simultaneously! In this case, restoring the system configuration data on
the system board would fail.
▶
Reconfigure the BIOS/iRMC and restore the system information like
server name, server model, housing type, serial number and
manufacturing data manually by Chassis ID Prom Tool.
Preliminary steps
▶
"Locating the defective server" on page 49.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
▶
If applicable, "Removing the riser module 2" on page 71.
▶
"Removing the fan cage" on page 74.
Front panel
