System state Power-on
indicator
Time
f System power (DC) on, BIOS setting
restore
Record of the following message on
SEL when completion.
Chassis IDPROM: BIOS restore
successful
green on About 3 minutes
g System reboot white on A few seconds
(5-10 seconds)
h
Active area BIOS restore form iRMC
microSD card
* Load and flash Active area BIOS
from the iRMC microSD card.
green on About 8 minutes
i Active area BIOS restore complete
Record of the following message on
SEL when completion.
BIOS TFTP or HTTP/HTTPS flash
OK
flashing
green and
white
A few seconds
(5-10 seconds)
j Active area BIOS boot check
*This check is performed because a
bootable BIOS needs to be written to
the recovery site.
green on About 1 minute
k System reboot white on A few seconds
(5-10 seconds)
l
Active area BIOS boot check
continued
green on About 3 minutes
Appendix A
RX2540 M6 Upgrade and Maintenance Manual 555
