Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Systems with PFR feature
System state Power-on
indicator
Time
a Power cord connected - -
b iRMC boot start, iRMC firmware
restore from iRMC microSD card
(included golden image), iRMC restart
Record of the following message on
SEL when completion.
When iRMC version in iRMC microSD
card and iRMC version of replaced
system board is dif
ferent:
iRMC Firmware %1 has been
successfully restored from SD
card.
The Golden Image has been
successfully restored from SD
card
When iRMC version in iRMC microSD
card and iRMC version of replaced
system board is same:
Restore of iRMC firmware %1
omitted because the already
flashed firmware has the same
version
flashing
white
About 13
minutes
When iRMC
version in iRMC
microSD card and
iRMC version of
replaced system
board is same,
the time is
shortened
because iRMC
firmware update
is skipped.
c iRMC boot complete, BIOS restore
prepare
white on About 1 minute
d System power (DC) on, BIOS setting
initialize
green on About 3 minutes
e System reboot white on A few seconds
(5-10
seconds)
Appendix A
554 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
