Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

System state Power-on
indicator
Time
d System power (DC) on, BIOS setting
initialize
green on About 3 minutes
e System reboot white on A few seconds
(5-10 seconds)
f
System power (DC) on, BIOS setting
restore
Record of the following message on
SEL when completion.
Chassis IDPROM: BIOS restore
successful
green on About 3 minutes
g System reboot white on A few seconds
(5-10 seconds)
h
BIOS firmware restore form iRMC
microSD card
* Load and flash BIOS from the iRMC
microSD card.
green on About 6 minutes
i BIOS firmware restore complete
* Load and flash BIOS from the iRMC
microSD card.
BIOS TFTP or HTTP/HTTPS flash
OK
white on -
Section d, f and h: the time it takes depending on memory and the number of
PCI cards installed. The above is the result of actual measurement without
loading a PCI card with two 8G memory modules.
From section c on, user can connect to iRMC web interface.
From section d onward, the screen will be displayed on the connected display.
Please check the screen.
Appendix A
RX2540 M6 Upgrade and Maintenance Manual 553

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
