The EDSFF SSD module is controlled by an onboard controller. For
more information, see the "Intel Virtual RAID on CPU (Intel VROC) User
Guide".
The VMD function has to be enabled in the BIOS.
If the VMD function is disabled in the BIOS, the EDSFF SSD module is
not supported.
CAUTION
All HDD/SSD modules (drives) must be uniquely identified so that they
can be reinstalled in their original bays later. If this is not done, existing
data can be lost.
Preliminary steps
▶
"Locating the defective server" on page 49.
▶
If applicable, "Removing the front cover with lock" on page
52.
▶
Identify the physical location of the EDSFF SSD module, see "Overview of
configurations" on page 188.
▶
Prepare the removing of the EDSFF SSD module.
▶
Depending on your configuration and OS: "Shutting down the server" on
page 52.
Removing the defective EDSFF SSD module
▶
Remove the EDSFF SSD module, see "Removing an EDSFF SSD module"
on page 194.
▶
If applicable, remove the EDSFF SSD from the installation frame, see
"Handling HDDs or SSDs without installation frame" on page 136.
Installing the new EDSFF SSD module
▶
If applicable, install the EDSFF SSD in the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 136.
▶
Install the EDSFF SSD module, see "Installing an EDSFF SSD module" on
page 192.
Hard disk drive (HDD) / solid state disk (SSD)
196 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
