Tools: – Phillips PH2 / (+) No. 2 screw driver (for cover 2)
– T
orx Plus 6 screw driver (not valid for Japan)
– Phillips PH1 / (+) No. 1 screw driver (Japan)
Preliminary steps
▶
"Removing backup and optical disk media" on page 90
.
▶
"Suspending BitLocker functionality" on page 87.
▶
If applicable, "Removing the front cover with lock" on page 52.
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page 53.
▶
"Getting access to the component" on page 56.
Removing the ODD
Figure 271: Unlocking the ODD cage
Accessible drives
RX2540 M6 Upgrade and Maintenance Manual 403
