Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

▶
"Getting access to the component" on page 56
.
▶
If a riser module is installed: Remove the corresponding riser module, see
"Removing a riser module" on page 70.
▶
If no riser module is installed: Remove the corresponding rear air grid, see
"Removing a rear air grid" on page 82.
Removing the slot cover
Figure 171: Removing the slot cover
▶
Remove the slot cover.
CAUTION
▶
Keep the slot cover for future use.
▶
If the expansion card is removed and not replaced with a new one,
the slot cover must be reinstalled due to cooling, to comply with
applicable EMC regulations and to protect against fire.
Installing the expansion card in a riser module
▶
Please read the documentation supplied with the expansion card.
▶
If applicable, install a slot bracket to the expansion card, see "Installing slot
brackets" on page 237.
Expansion cards and backup units
RX2540 M6 Upgrade and Maintenance Manual 281

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
