Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

There are two ways to update the golden image:
●
Update the golden image at the same time as the Active update (Both
mode).
●
Update the golden image using the Active image that has already been
written (Recovery mode).
The golden image can be updated only when the server is powered of
f.
Y
ou can update the golden image using the iRMC S5 web interface or the
Redfish API of the iRMC S5.
Updating the golden image using the iRMC S5 web interface
▶
Log in to the iRMC S5 web interface.
▶
Select the Tools menu.
▶
Open the Update page.
▶
In the BIOS Update group, set the Update Source to Image file.
▶
Set the Image to Flash to Both or Recovery.
▶
Click Start Update to Perform.
For more information on iRMC settings, see the iRMC user guides.
Updating the golden image using the Redfish API of the iRMC S5
Further information about the Redfish API of the iRMC S5, see the iRMC S5
Redfish documentation on the Fujitsu support internet pages at:
https://ts.fujitsu.com/support/
Basic software procedures
RX2540 M6 Upgrade and Maintenance Manual 119

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
