Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Power class Power PSU
4 1600 W AC PSU Platinum
1600 W HVDC PSU 380 V
5 2200 W AC PSU Platinum
All different PSUs can be installed, removed or replaced in the same
way.
Assembly rules
●
Mixed assembly of PSUs from different power classes (e.g. power class 1 or
power class 2) within a system is not supported.
●
Mixing of Platinum and T
itanium PSUs within same class (e.g. power class
2) within a system is not supported.
●
Mixing of Platinum PSUs within same power class and different
manufacturer (e.g. power class 1) within a system is supported.
●
Always install a dummy cover into an unused PSU bay to comply with
applicable EMC regulations and satisfy cooling requirements.
●
For a redundant power supply configuration you need always two PSUs with
the same power class.
Power supply unit (PSU)
RX2540 M6 Upgrade and Maintenance Manual 123

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
