Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

2.5-inch HDD/SSD subsystem
–
Up to 16 2.5-inch SAS/SAT
A HDD/SSD modules can be installed depending
on configuration.
The HDD/SSD modules are connected to the HDD backplane wirelessly.
This allows HDD/SSD modules to be plugged in or pulled out easily.
If the HDD/SSD modules are controlled by a RAID controller, defective
HDD/SSD modules can also be replaced during operation.
–
Up to 24 2.5-inch HDD/SSD/PCIe SSD modules can be installed depending
on configuration.
The HDD / SSD / PCIe SSD modules are connected to the HDD backplane
wirelessly. This allows HDD/SSD/PCIe SSD modules to be plugged in or
pulled out easily.
If the HDD/SSD/PCIe SSD modules are controlled by a RAID controller,
defective HDD/SSD/PCIe SSD modules can be replaced during operation.
For information on RAID controllers controlling the HDD/SSD/PCIe SSD
modules, see "Expansion cards and backup units" on page 233
.
EDSFF SSD subsystem
Up to 64 EDSFF SSD modules can be installed.
The EDSFF SSD modules are connected to the EDSFF backplanes wirelessly.
This allows EDSFF SSD modules to be plugged in or pulled out easily
.
Base units
There are six base units available.
Base unit Description
Type 1 Base unit with up to 10x 3.5-inch HDDs
Type 2 Base unit with up to 12x 3.5-inch HDDs
Type 3 Base unit for up to 16x 2.5-inch HDDs /SSDs
Type 4 Base unit for up to 24x 2.5-inch HDDs / SSDs /
PCIe SSDs
Hard disk drive (HDD) / solid state disk (SSD)
RX2540 M6 Upgrade and Maintenance Manual 135

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
