Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Figure 262: Removing the ODD latch from the ODD
▶
Remove the two screws (see circles).
▶
Remove the ODD latch.
▶
If no new ODD will be installed:
▶
Fasten the ODD latch with two screws to the chassis (see Figure 255).
Installing the dummy cover
Figure 263: Installing the dummy cover
▶
Insert the dummy cover and push it inward until it engages at the other side.
Accessible drives
RX2540 M6 Upgrade and Maintenance Manual 393

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
