Pos. Print Description
34 ROC Connector for Dual microSD 64GB Enterprise
cable
35 Internal USB 3 USB 3.0 connector (internal)
36 M.2 SSD 1 M.2 slot 1
37 M.2 SSD 2 M.2 slot 2
38 Micro SD Slot for micro SD card
39 HDD_led 3 LED activity connector 3
40 LC 2 Liquid cooling connector CPU2
41 TPM Connector for Trusted Platform Module (TPM)
42 SMB 3
43 Front Panel Front panel connector
44 PSU 2 Power supply connector hot-plug PSU 2
45 PSU 1 Power supply connector hot-plug PSU 1
Appendix A
RX2540 M6 Upgrade and Maintenance Manual 545
