Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Indicator Status Description
A -
Identification
blue on
The server has been highlighted using
ServerView Operations Manager
, iRMC
web interface or the ID button on the front
panel for easy identification.
blue flashing
The server has been highlighted for easy
identification using the iRMC (AVR) with
disabled local VGA output.
B - CSS
(Customer Self
Service)
off
No critical event detected (CSS
component).
orange on
Prefailure event detected (CSS
component).
orange flashing CSS component failure detected.
C - GEL
(Global Error
LED)
off
No critical event detected (non-CSS
component).
orange on
Prefailure event detected (non-CSS
component).
orange flashing
Non-CSS component failure detected.
Possible causes:
– System is out of the specified
temperature range
– Defective sensor
– CPU error
– Error detected by server management
software
F - Controller
off Controller okay
orange on
Controller failure (PCI card installed on riser
card)
G - CPU off CPU okay
orange on CPU failure
Appendix A
RX2540 M6 Upgrade and Maintenance Manual 547

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
