Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

Example HVDC PSU 380 V
A
Figure 6: Disconnecting the server from the dc voltage - example HVDC PSU 380 V
▶
Press the locking latch (A) of the power cord plug inside, until it disengages
(1).
▶
Disconnect the power cord from the PSU (2).
Basic hardware procedures
RX2540 M6 Upgrade and Maintenance Manual 55

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
