Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

17.4 Minimum startup configuration
Field Replaceable Units
(FRU)
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Component Notes
System board no TPM or expansion cards installed
1 CPU with CPU heat
sink
installed in CPU slot CPU 1
1 memory module installed in DIMM slot 1A
Common Operation
Panel (COP)
1 PSU installed in PSU bay PSU 1
Table 5: Minimum startup configuration - components
Cable Notes
Front panel cable
Power cable
Table 6: Minimum startup configuration - cables
▶
"Shutting down the server" on page 52.
▶
"Disconnecting the power cord" on page
53.
▶
Take the system down to its minimum startup configuration.
▶
"Connecting the power cord" on page 65.
▶
Connect a display to the server.
▶
Switch on the server, see "Switching on the server" on page 69.
Appendix A
568 Upgrade and Maintenance Manual RX2540 M6

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
