Installing the rear air grid 2
Figure 38: Installing the rear air grid 2
▶
Insert the rear air grid.
▶
Fasten the two screws (see circles).
Basic hardware procedures
RX2540 M6
Upgrade and Maintenance Manual
85
84
86
