Masterpiece
User Manual
Audio Transition Menu
In the Audio Transition menu you can setup the type of transition you want for the audio.
Touch one of the Transition Type buttons (the button will turn yellow when selected) at the top
of the menu to set the type of transition you require.
V-Fade - this button will perform a V-Fade transition. When the “Take Now” button is pressed,
this option will take the Program source to silent, then raise the audio up to the Preset source
level.
Fade and Take - this button will “Fade” the audio from one source down to silent and then cut
(the audio will instantly go back up to the full preset source level.
Mix - this performs a “Cross Fade”. When the “Take Next” button is pressed the audio from one
source will gradually fade out and at the Grass Valleye time the second source will gradually
fade in.
Take and Fade - this button will perform a cut to silent, then fade from silent up to the next
source level.
Cut - this button will perform a cut transition from one source immediately to the next.
50.00% - this will fade down to silent pause and then fade back up to the next source level.
The “Transition/On” buttons are used to select a second audio source that will contribute to a
live to air transition.
