Peripherals
Peripherals - Others
AMP Control
AMP protocol is an IP Based control structure, it will support 4 channels (VTR1, VTR2, VTR3, &
VTR4) in a single device, and also supports multiple devices over different IP Addresses.
Using AMP Control
Masterpiece can manage Folder (Bin) selection; set In and Out points, as well as the Standard
VTR type commands. It is recommended that Macros and/or Clones are used to assign these
controls to the main control surface.
The Peripherals - AMP File List menu allows the user to set the VTR that is being controlled
(green button at the top of the menu) and setup the working Folder Name and Clip Name lists.
The Clip Name table displays all the clips in the current working folder on the server.
{Refresh} button will refresh the Folder and Clip tables (e.g. if another controller adds a new
Folder/Clip).
{Load & Cue Clip} button will load and cue the currently selected clip to the currently selected
VTR.
Note: Name the device as required e.g. Server1, this name will appear
wherever the user needs to select it.
Note: If the server is not on a local network, an IP Gateway will be
required
Note: Each VTR can be set to contain different Folders/Clips.
Note: Masterpiece uses the Folder Name and Clip Name for reference.
