347
Masterpiece
User Manual
Camera - Shots Menu
This menu allows the user to store {Store Shot} up to 100 recorded robotic camera head
positions into registers, and recall them {Recall Shot} at any time.
Using the Store Shot
To use this function, the user will have to go back to the Camera Control Menu and touch either
the Pan, Tilt, Zoom or X, Y, Focus attacher (depending on the type of camera head used) then
press and hold down one of the 4 {MEM} buttons located next to the joystick. This will allow
the user to move the camera head using the joystick whilst in the Camera Shots menu.
Go back into the Camera Shots menu, select a camera head by pressing one of the available
buttons (in the top half of the menu), the button will turn Green when selected. Next use the
joystick to position the camera head, select a register position in the table, and then press the
{Store Shot} button.
The stored position can be recalled by scrolling to the required “Shot” and pressing the {Recall
Shot} button.
Store Shot
registers
