9
Masterpiece
User Manual
The Connect Menu
The Switcher Login column will show the mainframe the user can log into. Switcher Status
column will have the given name of the Switcher.
The Default Login button allows a panel to log in “Exclusively” and will prevent any other
panel(s) logging into the Masterpiece mainframe. To log in exclusively, select the {Default
Login} button, top right on the GUI Login.
If a panel is already logged into a switcher you cannot then log into it exclusively.
The Refresh button allows the user to refresh the display if other mainframes have been
connected whilst the mainframe is being used. Press the {Refresh} button and the system will
search for any other mainframes.
The Mainframe Finder menu, The “Mainframe Finder” menu is used to find mainframes when
the IP addresses of the mainframes and the control surface do not match.
If you cannot see the mainframe in this menu, touch the {Edit} button and a dialog box will
appear allowing you to type in the IP Address of the mainframe and touch the {Search Again}
button.
Mainframe Config
button displays
Name given to the
mainframe.
Mainframe serial
number
Switcher button
displays the name
of the switcher/s
