GRASS VALLEY MASTERPIECE User Manual

394
Peripherals
Peripherals - Others
In the “Connection” area of the menu (above top right), enter the IP address of the Masterpiece
mainframe and the Grass Valleye “Port Number” as was set when setting up the Masterpiece
protocol menu. Then set the “Encoding” parameter to ASCII.
In the “Message” window, type “MTR01, (number of macro) i.e. 022. This will trigger macro 22 in
the Masterpiece mainframe.
Note: Chyron will only Flash 1 or trigger the macro once on Masterpiece and
then cut the connection.
