1126800 SmartPAC 2 with WPC Integration
Page 104 Chapter 2 Installing SmartPAC 2 and WPC
Check and Set Direction of Resolver Rotation
DANGER!
INJURY DURING SETUP
Keep all personnel away from the press during setup.
Ensure that there is no die or other tooling in the press during setup.
Failure to comply with these instructions will result in death or serious injury.
NOTICE
If you turn the Prog/Run key and nothing happens, press RESET repeatedly until the
SmartPAC 2 changes modes.
If “PRESS CONTROL IS IN LOCKOUT MODE” appears on the display, turn the stroke
select key to OFF and then back to the desired operating mode to clear the message.
1. Make sure a tool number is loaded (see previous section.) Turn the Prog/Run key to Run.
2. Inch the press. Watch the crank angle on the display.
If the angle increases (goes up from 0 toward 359°), the resolver wiring is correct. Go
to the next section.
If the angle of the crankshaft decreases (goes down from 359° toward 0°) instead of
increasing, correct the resolver wiring (refer to Figure 1 at the end of the manual):
Swap the black and yellow wires at the WPC resolver connector TB105.
and
Swap the black and white wires at the SmartPAC 2 resolver connector TB101.
Inch the press again and watch the crank angle display.
If the angle increases, go to the next section to zero the resolver.
If the angle still decreases, contact Wintriss Tech Support.
