SmartPAC 2 with WPC Integration 1126800
SmartPAC Preventive Maintenance Appendix B page 439
(PM) Monitor
Table B - 1. Preventive Maintenance Items
air rotary seals back shaft bearing (1 through 4)
brake bull gear
clutch valve conveyor (1 through 6)
counterbalance system drive belts
DSV feeder
flywheel bearing gibs
lube filter lube motor
lube system main bearing (1 through 4)
main motor oil level
pilot solenoid pinion key
pitman bearing (1 through 4)
"Custom" name
Table B - 2. PM Tracking Units
run hours
1
days
weeks months
die changes ch. cycles (1 through 16)
2
F## WPC press control faults (#: 45 - 59)
3
press overloads
4
1
For SmartPAC (without WPC), "run hours" refers to the length of time that SmartPAC is "on.” For SmartPAC
with WPC, it means how long the motor is "on.” (The version of SmartPAC that you currently have is without
WPC. Contact Wintriss Tech Support if you require WPC.)
2
Ch. cycles 1 through 16 can be used only if you have a 16-channel ProCamPAC. Only ch. cycles 1 through 8
can be used for an 8-channel configuration.
3
These are only available if you have SmartPAC with WPC and if you have wired and assigned press functions
to the user-definable inputs. (The version of SmartPAC that you currently have is without WPC. Contact
Wintriss Tech Support if you require WPC.)
4
"Press overload" is only available with AutoSetPAC option.
