SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 73
0.35
(8.9)
TYP
Dimensions:
Inches (mm)
0.35
(8.9)
TYP
4.50
(114.3)
ENT E R
RESET
PROG RUN
POWER
BRAKE
WARNING
HELP
123
456
987
.
0
CLEAR
SmartPAC 2
F1
F2
F3
F4
F5
F6
F7
F8
NOTE:
SmartPAC and SmartPAC 2
both use the same size cutout:
9 x 11 inches. The top 9 holes
are in the same location.
If you are replacing a SmartPAC
with a SmartPAC 2, drill three
additional holes at the locations
shown for the bottom three holes.
10.65
(270.5)
11.00
(279.4)
11.30
(287.0)
12.30
(312.4)
0.35
(8.9)
TYP
8.65
(105.4)
9.00
(228.6)
10.70
(271.8)
5.50
(139.7)
0.35
(8.9)
TYP
Allow 6 inches (153 mm)
minimum clearance behind
the panel
Panel
Cutout
OFF
INCH
SINGLE
STROKE
CONT
Figure 2 - 19. SmartPAC 2 Mounting and Cutout Dimensions, Panel Mount
