1126800 SmartPAC 2 with WPC Integration
page 316 Chapter 5 SmartPAC 2 Program Mode
To enter information about the items:
1. Select the desired item. A screen overlay appears in which you can enter the appropriate
value. For Yes/no items, enter 0 (zero) for NO, and 1 (one) for YES.
2. Enter text into the memo box, by pressing F4 for the first line, and F5 for the second
line. A screen overlay (Figure 5-28) appears that enables you to enter fifteen characters
of numbers and alphabetic text for each line. When you complete each line, press F6 to
accept it.
A B C D E PRESS CLEAR TO CLEAR
F G H I J K TEXT. USE THE KEYPAD
L M N O P Q TO ENTER NUMBERS. USE
R S T U V W CURSORS TO SELECT THE
X Y Z , - # LETTERS. PRESS ENTER
. ( ) * / & TO ENTER THE LETTERS.
PRESS F6 WHEN DONE.
PRESS RESET TO CANCEL.
Figure 5 - 40. Text Entry Box
3. When you have finished entering information into the tool number information screen,
press RESET to return to the main Programming menu.
