SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 145
Single Stroke Mode Test Without Light Curtain(s)
DANGER!
INJURY DURING TESTING
Keep all personnel away from the press during testing.
Ensure that there is no die or other tooling in the press during testing.
Failure to comply with these instructions will result in death or serious injury.
DANGER!
CONTINUOUS MODE USED INADVERTENTLY
Disconnect the wiring to the “Continuous” position on the stroke select switch and cover the
“CONT” label on your control if you will not use your press in Continuous mode.
Failure to comply with these instructions will result in death or serious injury.
NOTICE
Refer to the WPC LED map, Figure B at the end of the manual.
NOTICE
WPC CONTROL BOARD LEDS
At this point, the “INCH SEL” LED should be off and the “SNGL STK SEL” should be lit.
Run this test if you do not use light curtains with your WPC installation.
1. Set the STROKE SELECT switch to SINGLE STROKE. Turn the Prog/Run key to Run.
2. Push and hold both RUN/INCH buttons.
3. Observe the ram’s motion.
• If the ram makes a full stroke and stops at or near top dead center, go to step 6.
• If the ram does not make a full stroke or does not stop at top dead center, go to step 4.
4. Observe the display.
• If the display shows an error code between F80 and F89 (or H80 through H89), this
indicates a problem with the overrun limit switch. To remedy, see the
troubleshooting information for these error codes in Chapter 7, the overrun limit
sensor switch instructions, “Install the Overrun Limit Sensor Magnetic Switch,” page
44, “Install Magnet for Overrun Limit Sensor,” page 116, and “Switches 1 and 2 –
Overrun Limit Switch Settings,” page 242. After you correct the problem, run the test
again, starting from step 2. If the ram still does not cycle or does not stop at top dead
center, contact Wintriss Tech Support.
