1126800 SmartPAC 2 with WPC Integration
Page 378 Chapter 6 SmartPAC 2 Run Mode
Using One-hand Control
DANGER
!
INSUFFICIENT SAFEGUARDS ALLOWING ACCESS TO HAZARD
• Follow all applicable OSHA and ANSI regulations for safeguarding your press system. Point
of operation safeguarding is the single most important factor in the prevention of injuries.
• Follow all applicable OSHA and ANSI regulations when installing one-hand control.
• Ensure that proper safeguarding devices are installed and working properly. Honeywell
takes no responsibility if safeguarding devices are not installed or working correctly.
• Ensure that guarding is properly installed to prevent access to the machine over, under or
around any guarding device.
• DO NOT use WPC or one-hand control as a safeguarding device
• Install and operate WPC and one-hand control in accordance with OSHA and ANSI
regulations.
Failure to comply with these instructions will result in death or serious injury.
DANGER
!
INCORRECT INSTALLATION
Shadow light curtains must be properly installed and connected to WPC in order to use ONE
HAND or FOOT modes.
Failure to comply with these instructions will result in death or serious injury.
NOTICE
With One-hand Control installed, you cannot use the run buttons in ONE HAND mode. All
other modes work normally as described in this manual.
One-hand Control is a switch that can only be used with any Wintriss Press Control systems
having One Hand and Single Stroke modes. One-hand Control must be used in conjunction
with a Shadow light curtain for guarding point of operation.
To start the press, the operator pushes the One-hand Control switch button as part of his
normal hand motion after loading a part.
"Light Curtain Break" Mode
You can use One-hand Control in "light curtain break" mode. In this mode, you must push
the switch button on the control within eight seconds after removing your hands from the
light curtain. Otherwise the press will not start. This mode prevents inadvertent operation
when an operator is loading or unloading parts. If this mode is not used, One-hand Control
starts the press whenever you push the One-hand Control. Enable “light curtain break” mode
by setting Option Switch 3 to CLOSED.
