Page #391 background image
SmartPAC 2 with WPC Integration 1126800
SmartPAC 2 Run Mode Chapter 6 page 369
One-hand Operation, Single Stroke Mode
DANGER
!
IMPROPER SAFEGUARDING
Ensure that the machine guarding system is installed and maintained according to OSHA
standard 1910.217, ANSI B11.1, ANSI B11.19 and any other regulations and standards that
apply. Ensure that guarding is properly installed to prevent access to the machine over,
under or around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
DANGER
!
INCORRECT INSTALLATION
Shadow light curtains must be properly installed and connected to WPC in order to use ONE
HAND or FOOT modes.
Failure to comply with these instructions will result in death or serious injury.
First, select ONE HAND in the mode select menu (page 365) and turn the stroke select key
to . To initiate a stroke, press the left RUN/INCH button. (The left RUN/INCH button must
be used, unless the operator station has an optional right/left hand selector switch.)
You can release that switch at any time, and the ram will complete the stroke. The ram, how-
ever, will stop if a system fault is detected or if the light curtain is blocked during the down
stroke.
