SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 57
Wiring Foot Switch (Optional)
DANGER!
UNGUARDED HAZARDS
Ensure that light curtains and other safeguards are properly installed and operating to
protect operators when using a foot switch.
Failure to comply with these instructions will result in death or serious injury.
DANGER!
IMPROPER FOOT SWITCH
Ensure that any foot control switch complies with OSHA 1910.217 (b) (7) (x), including
protection from accidental actuation by falling or moving objects or unintentional stepping on
the control.
Failure to comply with these instructions will result in death or serious injury.
The Foot Switch, when used with Shadow safety light curtains, frees up the operator’s hands
without sacrificing safety. Wire the Foot Switch’s normally closed contact to terminal #4
and the normally open contact to terminal #14 on the main processor board. Both switches
are then wired to +24 VDC. See Figure 3 at the end of this manual. Optional firmware is
required for Foot Switch operation. See “Switch 3 – One-hand Control or Foot Switch
Mode,” page 243., for foot switch settings.
