1126800 SmartPAC 2 with WPC Integration
Page 232 Chapter 4 SmartPAC 2 Initialization Mode
NOTICE
10% FOR OLD BRAKES, 20% FOR NEW BRAKES
The rule of thumb for determining the best stop time limit is to add 20% to the stopping time
of your press if your brakes are new. Add 10% if your brakes are old.
Here is the reasoning behind this rule. Stopping time should be less with a new brake. So
when the 20% is added to stopping time, the number should be approximately the same as
the number you get when you add 10% to stopping time for an older brake.
Examples for calculating the stop time limit
Example 1: Your recorded stopping time is 207 ms and your brake is old:
Take 10% of 207: T
bm
= .10 x 207 = 20.7
-- round it up to 21 --
Add 21 to 207 207 + 21 = 228
228 ms is the calculated stop time limit.
Example 2: Your recorded stopping time is 175 ms and your brake is new:
Take 20% of 175: T
bm
= .20 x 175 = 35
Add 35 to 175 175 + 35 = 210
210 ms is the calculated stop time limit.
Setting Stop Time Limit at Press Parameters
NOTICE
To enable changes to Stop Time or Auto Carry-up Angle, you must first set Switch 7 to
OPEN, power down SmartPAC 2 and power it up again, as instructed below.
1. Go to the Main Initialization menu (Figure 4 - 1), and select "Press Control.” The WPC
Initialization menu appears. Select “Press Options.” In the menu that appears, set Switch
7 to OPEN to enable changes (see page 247). Power down SmartPAC 2 with WPC and
power it up again to make the new switch setting take effect.
2.
Go to the SmartPAC's Main Initialization menu (Figure 4 - 1), and select "Press Control.”
The WPC Initialization menu appears (see next figure).
