SmartPAC 2 with WPC Integration 1126800
SmartPAC 2 Initialization Mode Chapter 4 page 247
Switch 7 –Disable Changes to Stop Time Limit and Auto Carry-up Angle
NOTICE
After you change switch settings, power down the SmartPAC 2/WPC. Power it up again to
enable the new settings. If you do not this, the previous switch settings will remain in effect.
With this switch OPEN, you can change the settings for Stop Time Limit and Auto Carry-up
Angle. When this switch is set to CLOSED, you cannot change these settings.
Table 4 - 10. Switch 7 Setting to Enable/Disable Changes to Stop Time Limit
and Auto Carry-up Angle
Option Switch 7 Setting
Changes to
Stop Time Limit and Auto Carry-up Angle
OPEN Enabled
CLOSED Disabled
NOTICE
CHANGE FROM PREVIOUS VERSIONS OF WPC: TOP STOP IN INCH DISABLED WITH
INPUT PIN 13
To disable top stop in inch, connect on the WPC processor board, connect Pin # 13 to
+24 VDC. (Previous versions used Switch 7)
