1126800 SmartPAC 2 with WPC Integration
Page 368 Chapter 6 SmartPAC 2 Run Mode
mode (Figure 6-14). By pressing the designated function key you can disable or enable
Micro Inch when running the press in INCH.
For details on Micro-inch mode, refer to the section "Setting Micro-Inch Time and Angle,"
page 236, and “Mode Select Menu,” page 365.
NOTICE
If an Interrupted stroke occurs, WPC automatically switches to TWO HAND MAINTAINED
SINGLE STROKE, even if Micro-inch is enabled. See “Interrupted Stroke,” page 364.
Operating the Press in Single Stroke Mode
DANGER
!
IMPROPER SAFEGUARDING
Ensure that the machine guarding system is installed and maintained according to OSHA
standard 1910.217, ANSI B11.1, ANSI B11.19 and any other regulations and standards that
apply. Ensure that guarding is properly installed to prevent access to the machine over,
under or around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
One-hand Operation, Single Stroke Mode, next section
Two-hand Operation, Single Stroke Mode, page 370
Foot Operation, Single Stroke Mode, page 372
Operating the Press in Automatic Single Stroke Mode, page 373
1. If you have the foot or one-hand option, and want to use it, select it in the mode select
menu (page 365).
2.
Set the stroke select switch to SINGLE STROKE. See the following sections for
instructions for each setting.
NOTICE
ONE HAND and FOOT modes do not exist on Two-hand Only systems.
