SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 55
Part 3 – Install and Wire WPC Options
Wiring Lockout Relay (Optional), next section
Wiring a Remote Reset Switch (Optional), next page
Wiring Operator Mode Outputs (Optional), page 56
Wiring Foot Switch (Optional), page 57
Installing One-hand Control (Optional) , page 58
Wiring Automatic Single Stroke/External Trip, page 62
Wiring Continuous on Demand, page 62
Installing Multiple Operator Stations, page 63
Auxiliary Outputs (Optional), page 64
Wire a Keylock Switch to Prevent Changes to WPC Settings in Program and Run (Optional),
page 66
Installing Flywheel Speed Sensor (Optional Hardware Required), page 67
Mounting and Wiring the Bar Control Enclosure (Optional) , page 68
NOTICE
HIGH SPEED OPTION FOR SMARTPAC 2 WITH WPC
To set up the High Speed option for SmartPAC 2 with WPC, see “Set Up High Speed
Version of SmartPAC 2 with WPC,” page 94
Wiring Lockout Relay (Optional)
The lockout function in WPC provides an added safety feature to the product. Whenever a
serious error condition occurs, a lockout warning message appears on the SmartPAC 2
display alerting you of a problem. To clear a lockout condition, turn the STROKE SELECT
key switch toward “OFF” and then back to the desired operating mode.
To wire this relay to the WPC power supply board, refer to the wiring schematics at the end
of this manual (Figure 4 for Herion DSV or Figure 6 for Ross). Note that the relay can be
wired to critical press functions, such as the motor starter (see Figure 7 for an example).
