Honeywell SmartPAC 2 User Manual

1126800 SmartPAC 2 with WPC Integration
Page 54 Chapter 2 Installing SmartPAC 2 and WPC
Table 2 - 2. User Inputs (Interlocks), SmartPAC with WPC
USER INPUT
(INTERLOCK)
STOP TYPE
WIRE
TO
PIN #
WIRE TO
(JUMPER TO
BYPASS)
FAULT
CODE
NAME OF
AUXILIARY
EQUIPMENT
User #1 21 +24 VDC 51
User #2 82 +24 VDC 52
User #3 71 +24 VDC 53
User #4 83 GROUND 54
User #5 72 GROUND 55
User #6 84 GROUND 56
User #7
73 GROUND 57
User #8 *
paired with #9
ESTOP
or
ESTOP/
LOCKOUT
85 GROUND
58, 17
User #9 *
paired with #8
ESTOP
or
ESTOP/
LOCKOUT
74 GROUND
User #10 *
paired with #11
ESTOP
or
ESTOP/
LOCKOUT
86 GROUND
50, 18
User #11 *
paired with #10
ESTOP
or
ESTOP/
LOCKOUT
18 GROUND
* On older versions of WPC these inputs had different functions. Be sure to
wire these inputs correctly according to the needs of your installation. If any of these
inputs are not used, you must install jumpers as indicated to bypass the inputs.
