SmartPAC 2 with WPC Integration 1126800
SmartPAC 2 Program Mode Chapter 5 page 319
THAT INPUT IS TURNED OFF.
PRESS ENTER TO CONTINUE,
PRESS RESET TO GO BACK.
TO TURN ON THE INPUT TURN
KEY TO PROGRAM AND SELECT
“SENSOR ENABLE. DISABLE STATUS”
FROM THE MENU.
RECALCULATE SETPOINTS (Optional)
(PROGRAM – RECALCULATE SETPOINTS)
To recalculate the setpoints for your SmartPAC 2 tonnage monitor option, select this item in
the main Program menu, Figure 5 - 11. If you have SmartPAC 2 recalculate the setpoints,
the new setpoints will replace the existing setpoints, as described in your load monitor
manual.
The following warning box appears.
Figure 5 - 42. Recalculate Setpoints Warning Box
• If you want to have the setpoints recalculated, press ENTER.
• If you do not want to have the setpoints recalculated, press RESET.
If you pressed ENTER, the following message appears briefly while SmartPAC 2
recalculates the setpoints.
Setpoints will be recalculated
