SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 59
Button
Shroud
top view
side view
Dimensions: inch
(mm)
Conduit opening
3.88
(98.6)
4.00
(101.6)
2.50 dia.
(63.5)
4.5
(114.3)
3.25 dia.
(82.6)
Base
Cover
Figure 2 - 12. One-hand Control Switch Dimensions
