Page 224 Chapter 4 SmartPAC 2 Initialization Mode
NAME UNITS PLACES
TOOL 1 PASS LINE HT IN 2
INFO. 2 STRAIGHTENER IN 2
NAMES 3 HYD. OVLD. TONS 0
4 PRESS SPEED SPM 0
5 CONVEYOR 8
6 PART LUBE 8
USE CURSOR KEYS TO SELECT A NAME. PRESS
ENTER TO CHANGE. PRESS RESET WHEN DONE.
PASS LINE HT
Figure 4 - 21. Completed Tool Number Information screen
NOTICE
Do not change the number of decimal places after you have entered values for any specific
tools. If you change the number of decimal places, any value you entered will be changed
by a factor of ten for each decimal place added or removed.
5. When you have finished setting up the tool number information, press RESET to return
to the main Initialization menu.
Table 4 - 3. Decimal places and formats
Number of decimal places
Example
digits to digits to
left of right of
decimal decimal
point point
Range
0
whole numbers: press speed (SPM )
up to none (0)
seven (7)
0 to
9,999,999.
1
up to one (1)
five (5)
0.0
99,999.9
2
die location (mm)
up to two (2)
four (4)
0.00
9,999.99
3
pass line height (inches)
up to three (3)
three (3)
0.000
999.999
4
precise values: material thickness
up to four (4)
two (2)
0.0000
99.9999
8
Yes or No designation
not applicable
NO (0)
YES (1)
