1126800 SmartPAC 2 with WPC Integration
Page 58 Chapter 2 Installing SmartPAC 2 and WPC
Installing One-hand Control (Optional)
DANGER
!
INSUFFICIENT SAFEGUARDS ALLOW ACCESS TO HAZARD
Follow all applicable OSHA and ANSI regulations for safeguarding your press system. Point
of operation safeguarding is the single most important factor in the prevention of injuries.
Follow all applicable OSHA and ANSI regulations when installing one-hand control.
Ensure that proper safeguarding devices are installed and working properly. Honeywell
takes no responsibility if safeguarding devices are not installed or working correctly.
DO NOT use WPC or one-hand control as a safeguarding device
Install and operate WPC and one-hand control in accordance with OSHA and ANSI
regulations.
Failure to comply with these instructions will result in death or serious injury.
One-hand Control is a switch that can only be used with Wintriss Clutch/Brake Control systems with
a Shadow light curtain that have ONE HAND and SINGLE STROKE modes.) One-hand Control
must be used in conjunction with a Shadow light curtain for guarding point of operation. One-hand
Control is mounted on or near the press and allows the press operator to cycle the press without
using the operator station. Optional firmware is required for One-hand operation. See also wiring
diagram, Figure 9, at the end of the manual.
To cycle the press, you simply push the button as part of your normal hand motion after you
load a part.
Mounting One-hand Control Switch
DANGER
!
OPERATOR CONTROL TOO CLOSE TO HAZARD
Mount the one-hand control outside the area protected by the light curtain. DO NOT mount
the one-hand control between the light curtain and the point of operation.
Failure to comply with these instructions will result in death or serious injury.
1. Shut off power to the press and WPC.
2. Choose a location on or near the press convenient to the operator. An adjustable bracket
may be necessary.
The idea is to mount One-hand Control so the operator can reach it as part of his normal
hand movement after loading or unloading a part. Mount One-hand Control using the
tapped holes on the bottom of its metal enclosure (see below).
