1126800 SmartPAC 2 with WPC Integration
Page 136 Chapter 2 Installing SmartPAC 2 and WPC
System Static Test
ARNING
!
ELECTRIC SHOCK HAZARD WHEN WORKING INSIDE ENCLOSURE WITH POWER ON
• DO NOT touch electrical connections or circuit boards.
• Ensure that this test is performed by qualified personnel.
Failure to comply with these instructions could result in death or serious injury.
NOTICE
Refer to the WPC LED map, Figure B at the end of the manual, and “Using the WPC Status
Display,” page 420.
1. Turn off the system air and bleed down the system (clutch) air pressure.
2. At the SmartPAC 2, set the Prog/Run key to RUN and the STROKE SELECT switch to
INCH.
3. The display shows the crank angle. Notice whether the INTERRUPTED STROKE
message flashes on the display.
• If the INTERRUPTED STROKE message is on, go to the next step.
• If the INTERRUPTED STROKE message is off, check inside the control enclosure,
at the WPC control board, whether “INCH SEL” LED is on. If it is not, check the
stroke select switch wiring and correct any problems. If the “INCH SEL” LED is still
off, contact Wintriss Tech Support.
4. At the Operator Station, press and hold the EMERGENCY STOP / RESET button.
5. Notice that “F13” appears on the display.
• If a status code “F13” appears, go to the next step.
• If “F13” does not appear, at the WPC control board, check whether the “E-stop #1
input” and “E-stop #2 input” LEDs turn off when the EMERGENCY STOP / RESET
button is pressed. If they do not turn off, check the wiring and correct any problems.
If they still do not turn off, contact Wintriss Tech Support.
6. Turn on the press motor (forward rotation, if applicable).
7. At the WPC control board, check whether the “Motor Forward” LED is on when the
motor is running in the forward direction.
• If the Motor Forward LED is on, go to the next step.
• If the Motor Forward LED is off, check the wiring and correct any problems. If it is
still off, contact Wintriss Tech Support.
8. At the Operator Station, push both RUN/INCH buttons at the same time.
