SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 135
Check the Top Stop Circuit
DANGER!
INJURY DURING TESTING
Keep all personnel away from the press during testing.
Ensure that there is no die or other tooling in the press during testing.
Failure to comply with these instructions will result in death or serious injury.
Run the press in Continuous mode, and depress the TOP STOP button. The press should
stop at top dead center.
• If the press top stops, go to the next test.
• If the press does not top stop, there is a problem in your top stop circuit. Recheck
wiring and correct the cause of the problem. Re-run this test. If the press does not top
stop, contact Wintriss Tech Support. Do not run the press or continue with this
checkout procedure until the press top stops correctly.
NOTICE
CHECKING THE TOP STOP CIRCUIT IN SINGLE STROKE MODE
If your press does not run in continuous mode, run this test while holding down the run
buttons in Single Stroke mode.
