1126800 SmartPAC 2 with WPC Integration
Page 220 Chapter 4 SmartPAC 2 Initialization Mode
Enabling or Disabling Setup Mode
(INITIALIZATION - SENSOR ENABLE MODE)
NOTICE
If your SmartPAC 2 is not integrated with a WPC, your inch-selector switch must be wired to
the setup mode input, terminal #252 on TB107.
If you enable Setup mode, the green sensors are disabled in the condition you choose:
• In Inch mode
or
• In Inch mode and in Interrupted-stroke mode. (Available only with WPC integration)
For more information, see the Initialization chapter in your user manual.
1. To enable or disable Setup mode, in the Main Initialization menu, select SENSOR
ENABLE MODE.
MAIN INITIALIZATION MENU
USE THE CURSOR RESOLVER ZERO
KEYS TO CHOOSE POSITION SENSOR
MENU ITEMS. PRESS INSTALLED OPTIONS
THE ENTER KEY TO SELECT CAM NAMES
SELECT. SWITCH TO AUTO ADVANCE
RUN WHEN DONE. CUSTOM SENSOR NAMES
SENSOR ENABLE MODE
PROCESS MONITOR
TOOL INFORMATION
RAMPAC INIT
PRESS CONTROL
SECURITY ACCESS
SENSOR ENABLE MODE
Figure 4 - 15. Main Initialization Menu
A screen similar to the following appears.
DIE PROTECTION MODE SELECTION MENU
SENSOR ENABLE MODE = AUTO BY TOOL
SETUP MODE = DISABLED
USE THE CURSOR KEYS TO SELECT THE MODE
YOU WANT TO CHANGE. PRESS THE ENTER KEY
TO CHANGE IT. PRESS THE RESET KEY WHEN
YOU ARE DONE.
DISABLED
Figure 4 - 16. Setup Mode Status
