SmartPAC 2 with WPC Integration 1126800
SmartPAC 2 Keyboard, Displays Chapter 3 Page 181
and Operating Modes
ENTER and RESET Keys
Use these keys to navigate through the menus and to perform different actions as described
on the screens.
ENTER Key
ENTER
RESET
PROG RUN
POWER
BRAKE
WARNING
HELP
123
456
987
.
0
CLE AR
SmartPAC 2
F1
F2
F3
F4
F5
F6
F7
F8
CAMBIE
AL ESPANOL
ENTER
key
ENTER
Figure 3 - 11. ENTER Key
NOTICE
SELECT = HIGHLIGHT + ENTER
When this manual says “select,” it means highlight the item and press ENTER.
To choose an item on a menu, use the cursor keys (see “Cursor Keys, above) to highlight the
item you want on the menu. Then press the ENTER key. SmartPAC 2 goes to the display
relating to the item you selected.
You also use the ENTER key at other times, to accept a number you keyed in, or to start
loading a settings for a tool.
