SmartPAC 2 with WPC Integration 1126800
SmartPAC 2 Fault Messages Chapter 7 page 385
What Happens When You Get a Fault Message
If an error or fault occurs, a red message box will appear, similar to the following, giving the
error code and a brief explanation of the error
Figure 7 - 2. Error Code Box
If the press stops because one of the counter presets count is reached, a yellow message box
appears, similar to the following, telling which counter preset has been reached.
Figure 7 - 3. Counter Preset Message Box
How to Clear the Fault Message from the Display
To resume operation after an error message occurs, clear the error message by pressing the
RESET key (or Remote Reset Button, if installed). Correct the malfunction or other problem
before running the press.
If you cannot correct the problem after reading the remedy, contact Wintriss Tech Support.
NOTICE
PROVIDE IMPORTANT INFORMATION WHEN CALLING WINTRISS TECH SUPPORT
When you contact Wintriss Controls for technical assistance, be ready to provide some
important information to expedite a resolution to the problem. Please supply: product name
(e.g. SmartPAC 2 standard); installed options (e.g. DiProPAC, ProCamPAC, etc.); and
firmware version number (e.g. Vs. 2.00). You can determine the last two items, by going into
"Installed options" in the Initialization mode (see Chapter 4 for details).
