SmartPAC 2 with WPC Integration 1126800
Installing SmartPAC 2 and WPC Chapter 2 page 151
Foot Switch Test (with Optional Foot Switch)
DANGER!
INJURY DURING TESTING
Keep all personnel away from the press during testing.
Ensure that there is no die or other tooling in the press during testing.
Failure to comply with these instructions will result in death or serious injury.
DANGER!
MISSING SAFEGUARDS
Install a light curtain for use with the foot switch option. A light curtain is required for using
the foot switch.
Failure to comply with these instructions will result in death or serious injury.
W
ARNING
!
ELECTRIC SHOCK HAZARD WHEN WORKING INSIDE ENCLOSURE WITH POWER ON
DO NOT touch electrical connections or circuit boards.
Ensure that this test is performed by qualified personnel.
Failure to comply with these instructions could result in death or serious injury.
Perform this test only if your SmartPAC 2 with WPC is equipped with a Foot Switch. If
necessary, refer to the LED map, Figure B at the end of the manual, when you are directed to
the WPC control board.
NOTICE
These instructions refer to the Auto Carry-up angle, which is factory set to
170° if it does not have a light curtain.
149° if the press does have light curtain
Refer to instructions for using Auto Carry-up, page 235 for detailed information about the
Auto Carry-up feature.
1. Set the STROKE SELECT switch to OFF and set the MODE to FOOT. Now, set the
STROKE SELECT switch to SINGLE STROKE
2. Set Press Option switch 3 OPEN. Remember to power down, then power back up to
enable the change. The WPC is now in the FOOT TRIP mode. After it is tripped, the
press should run to top stop. On the WPC control board, the “Continuous selector” LED
should be off, the “Single Stroke select” LED should be on, and the “Foot selector” LED
should be on.
