Page 228 Chapter 4 SmartPAC 2 Initialization Mode
See Table 4 - 4, below, for a complete list of pre-programmed names. Select “CUSTOM
NAME” if you want to enter a name not on the list.
SELECT STOP TYPE
USE THE CURSOR KEYS
TO TO MAKE SELECTION.
PRESS ENTER TO SET.
RESET WHEN DONE.
MORE NAMES
UNNAMED
CUSTOM NAME
BEARING TEMP.
CHAIN BREAK
CONVEYOR
COUNTER BAL.
DIE NITROGEN
DIE PROTECTION
DUAL VALVE
END OF STOCK
FEEDER
HIGH AIR PRES.
HIGH LOOP
HIGH OIL PRES.
HYDRAULIC OVLD
LOAD MONITOR
UNNAMED
Figure 4 - 24. "Select Name" Display
NOTICE
The name you enter for Input 8 applies to the input pair 8 & 9, regardless of what name you
enter for Input 9.
The name you enter for Input 10 applies to the input pair 10 & 11, regardless of what name
you enter for Input 11.
Table 4 - 4. User Input (Interlock) Names
UNNAMED HIGH LOOP RECOILER
“CUSTOM” NAME HIGH OIL TEMP. STOCK BUCKLE
BEARING TEMP. HIGH OIL PRES. TRANSFER
CHAIN BREAK HYDRAULIC OVLD STR/OFF COILER
CONVEYOR LOAD MONITOR STOCK LUBE
COUNTER BAL. LOW AIR PRESS. HYD DIE CLAMPS
DIE NITROGEN LOW OIL LEVEL SLUG BUCKET
DIE PROTECTION LOW OIL PRESS. SBL MEASUREMNT
DUAL VALVE LUBE PROBLEM OFF COILER
END OF STOCK MISFEED STRAIGHTENER
FEEDER MISFEED PILOT
HIGH AIR PRES. MOTOR OVLD.
4. Use the down cursor key to scroll to the name you want to use for input pair 8 & 9. Press
ENTER to select that name. If you choose “‘CUSTOM’ NAME,” a screen appears for
entering the name. Otherwise, the display returns to the User Interlock menu.
