SmartPAC 2 with WPC Integration 1126800
SmartPAC 2 Initialization Mode Chapter 4 page 233
WPC INITIALIZATION MENU
USE THE CURSOR KEYS USER INTERLOCKS
TO SELECT THE ITEM PRESS PARAMETERS
YOU WISH TO SEE. PRESS OPTIONS
PRESS ENTER TO INPUT STATUS
ACCESS IT. PRESS
RESET WHEN DONE.
USER INTERLOCKS
Figure 4 - 28. WPC Initialization Menu
3. Select “Press Parameters." The Press Control Parameter menu appears (next figure). Use
the cursor keys to highlight "Stop Limit" in the display shown below. Then press
ENTER to select.
TOP STOP DEFLT
CARRYUP ANGLE
MICRO TIME
MICRO ANGLE
MAIN AIR LIMIT
CNTR BAL +/-
STOP LIMIT
START LIMIT
SHUT DOWN LIMIT
FLYWHEEL TIMER
ACTS ANGLE
220 DEG
149 DEG
100 MSEC
185 DEG
0 PSI
0 PSI
250 MSEC
199 MSEC
5 MIN
6 SEC
0 DEG
=
=
=
=
=
=
=
=
=
=
=
INITIALIZE PARAMETERS
USE THE CURSOR KEYS TO CHOOSE THE VALUE
YOU WANT TO CHANGE.
PRESS THE ENTER KEY TO CHANGE THE VALUE.
PRESS THE RESET KEY WHEN DONE.
PRESS CONTROL PARAMETER MENU
250
Figure 4 - 29. "Press Parameters" Display in SmartPAC's Initialization Mode
4. The bar highlights the Stop Time Limit value. To change this value, press ENTER. Now
the message at the bottom of the display reads
5.
Use the number keys to change the Stop Time Limit. Press ENTER to accept the change.
Use the cursor key to select the Start Time Limit value. Do as you did in step 2 for start
time limit. Press RESET when done. The WPC Initialization menu appears.
6.
Select "Press Control.” The WPC Initialization menu appears. Select “Press Options.”
In the menu that appears, set Switch 7 to CLOSED to disable changes (see page 247).
To Next Page
